RIFLESCOPE FEATURES:
- One-piece oversized 34mm tube increases strength and reliability and provides greater elevation and windage adjustments for longer ranges.
- Broadband anti-reflection coatings for 94% + light transmission to ensure optimal performance in low light.
- Optimized exterior design with larger, positive grip elevation, windage, parallax and illumination knobs and nonslip diopter and magnification adjustment.
- Illuminated reticle with seven night and four-day levels with two “OFF” positions at each end, and quick standby levels between each for fast return setting.
- Precise windage/elevation adjustment is easy and accurate for repeated accuracy, with tactile click-by-click feedback you can hear and feel.
- Shockproof and rugged enough to withstand impact testing to 900 Gs on all optical and electronic components.
RIFLESCOPE SPECIFICATIONS:
Magnification: 5.25x
Objective lens diameter: 56 mm
Reticle: MSR2
Tube Diameter: 34 mm
Field of view @ 100 meters: 4.6m – 23.6m
Exit Pupil: 2.2mm – 9.8mm
Focal Plane: FFP (First Focal Plane)
Parallax/Focus Range: 50m to INF
Click Value: 1 cm
Diopter Adjustment Range: +2 to -3
Wind Range at 100 m: +/- 60 cm
Elevation Adjustment Knob: Duo Scale / Resettable Zero
Elevation Range: 260 cm
Eye Relief: 3.5 in – 4.3 in
Illumination Control: Rotary Digital Control w. Intermediate Stops
Length: 16.6 in
Weight: 36.3 oz
Waterproof/Fogproof: Submersible to 33 ft
Special Features: Resettable Turrets, Second Rotation Indicator, Zero Stop
Included Accessories: Battery, Lens Cloth, Lens Cover
Warranty: Heritage™ Warranty
